PHP/Javascript SVG Transformations Tutorial

Posted on by
PHP/Javascript SVG Transformations Tutorial

PHP/Javascript SVG Transformations Tutorial

Yesterday’s PHP/Javascript SVG Text and Group Tutorial started us off on the concept of SVG g groups, and it is natural from there we should discuss the SVG transform transformations …

… and what is important to the end result of a combination of these, the order in which we decide the user should control. With that order in mind, though we were sorely tempted to introduce an HTML select (dropdown) element, to be the user interface selecting these transformations, we instead opted for input type=button elements where the advantage is the user sees all before their very eyes. Non-mobile people could see all too via a size=6 argument to a select element, but this is not honoured in mobile platforms, so we persevere with buttons.

More scope with settings data length, and you will not be surprised us telling you we can easily get “REQUEST-URI too long” errors without a test of the length of a proposed ? and & based (web browser address bar) URL, in which case we can handle this, having written the web application in serverside PHP, to then revert to navigation via …

  • form style=display:none; action=[here’sLookingAtYouKid] method=POST … versus GET (is the ? and & way) …
  • input type=hidden elements whose values cover that same settings data requirements … and …
  • input style=display:none; type=submit element clicked, programmatically

… as required.

For today’s live run‘s transformational work SVG_Primer.php changed in this way.

Previous relevant PHP/Javascript SVG Text and Group Tutorial is shown below.

PHP/Javascript SVG Text and Group Tutorial

PHP/Javascript SVG Text and Group Tutorial

It’s well overdue for us to revisit SVG (Scalable Vector Graphics) …

SVG is short for Scalable Vector Graphics. It is a graphic format in which the shapes are specified in XML. The XML is then rendered by an SVG viewer. Today most web browser can display SVG just like they can display PNG, GIF, and JPG.

… issues last talked about, for us, with PHP/Javascript SVG YUI Geometry Tracing Tutorial some time ago.

We first became aware of SVG “Groups” by examining the innards of Google Chart charts. Many of this great series of online chart functionalities by Google use the SVG g elements as a means by which you can conglomerate other SVG graphical bits and pieces into another graphical entity, shall we say, that can have a transformation applied to it (as a whole), if you like, and we like today, allowing for a very rudimentary rotation option. All this happened via a newly introduced button labelled “Group and draw shape(s) above”. Cute, huh?! And a bit oh, oh O.O.ish, as in another approach à la …

Another new aspect to SVG usage we add into our SVG Primer web application live run functionality is the ability to place text, using the … anyone, anyone … yes, Teodoro Obiang Nguema … the SVG text element.

As far as text goes, in particular, you may find it like holding a hose three quarters of the way up with a heavy stream of water passing through it! It’s hard to control exact placement, but who knows whether that is the be all and end all, for you, and its use with SVG you need to apply to a project you have on your plate.

For today’s work SVG_Primer.php changed in this way.

Previous relevant PHP/Javascript SVG YUI Geometry Tracing Tutorial is shown below.

PHP/Javascript SVG YUI Geometry Tracing Tutorial

PHP/Javascript SVG YUI Geometry Tracing Tutorial

We came across another great “Geometry Tracing” functionality possibility the other day. It revolved around using the excellent YUI (by Yahoo) library of Javascript functionality, and we wanted to integrate it into yesterday’s PHP/Javascript SVG Geometry Tracing Tutorial start to our software integration journey of late. Before going on, we’d like to thank Graphics: Path Drawing Tool – YUI Library for the basis in code of today’s supervised additions in HTML and Javascript and CSS web application components.

To involve Javascript libraries like YUI is more than a Javascript dynamic HTML “workings” experience. Built in, if you choose to access it … all free, thanks … are a lot of aesthetically pleasing stylesheet ideas, and this shows with our “better than usual” look to our supervised YUI web application components.

What we have now is as below, with the bold section new for today’s work.

We like YUI’s pencil as the draggable cursor that the user can use to trace around their SVG … again via …

  • ?area=[parent determined area of SVG element]
  • &svg=[data URI of SVG xml]

… GET call of the YUI magic!



elem.style.backgroundRepeat='no-repeat';
elem.style.backgroundPosition='20px 20px';
elem.style.backgroundImage='url(' + ourtowhat + ')';

… and this started working for Firefox, at least. Hopefully the Windows browsers as well?!

Previous relevant PHP/Javascript SVG Geometry Tracing Tutorial is shown below.

PHP/Javascript SVG Geometry Tracing Tutorial

PHP/Javascript SVG Geometry Tracing Tutorial

The tutorial today is about software (web application) integration that is value adding but in an optional way. The software integration is between …

We integrate these two in quite a neat way, allowing for the extension of the supervised’s static arrays which go …


var imageo=[];
var ourareawas=[36213.0, 25382.0, 19608.0, 39366.5, 24471.5, 43679.5, 37633.5, 45130.5, 40987.5, 51842.5];
var image_array=["one_sided.jpg", "two_sided.jpg", "three_sided.jpg", "four_sided.jpg", "five_sided.jpg", "six_sided.jpg", "seven_sided.jpg", "eight_sided.jpg", "nine_sided.jpg", "ten_sided.jpg"];

… extended by Javascript’s [array].push method (often good for those dynamic Javascript DOM driven extensions of functionality) … to establish the (communication protocol) ideas for the “Geometry” the user can be “Tracing” around, by allowing new GET parameters …

  • ?area=[parent determined area of SVG element]
  • &svg=[data URI of SVG xml]

… the latter of which we’re using for the first time in this project, and want to thank the Data URI’s for SVG paragraph for great ideas here. As you do software integration, sometimes you think of it as a slog, and yes, it usually is a bit of a slog. When the slog is more a neat data efficient form of integration, that Data URIs for SVG seems to us to be, then it all seems worthwhile.


And so you can see us integrating the display of an SVG piece of geometry to offering the user the (optional) chance to play a game seeing how accurately they can trace around that shape and match the supervisor calculated mathematics (Area of a Polygon) algorithm (we use a lot in various web applications) generated area value. Value adding, and entertainment adding, we think … we hope.

You can also see this play out at WordPress 4.1.1’s PHP/Javascript SVG Geometry Tracing Tutorial.

Previous relevant PHP/Javascript SVG Colour Picker Tutorial is shown below.

PHP/Javascript SVG Colour Picker Tutorial

PHP/Javascript SVG Colour Picker Tutorial

Today’s posting hooks up two HTML5 concepts, as described below …

  • The HTML5 specification allows for the display of 2D-graphics via SVG HTML tags which use graphical applications in XML and the XML is then rendered by a SVG viewer. SVG stands for Scalable Vector Graphics.
  • The HTML5 specification added some new very useful HTML input element types, and today, we’re talking about the type=color element type that brings up a pretty suave colour picker helper, in some browsers

There are alternative colour pickers out there, in addition to what HTML5 has given us, and you may want to read YUI UI Colour Picker Primer Tutorial about that.

Today, we’ll leave you with SVG_Primer.php changed from PHP GD and Image Functions Primer Tutorial‘s version in this way. And before you leave, you could create your own SVG elements via this live run link.

Previous relevant PHP/Javascript SVG Primer Tutorial is shown below.

PHP/Javascript SVG Primer Tutorial

PHP/Javascript SVG Primer Tutorial

The HTML5 specification allows for the display of 2D-graphics via SVG HTML tags which use graphical applications in XML and the XML is then rendered by an SVG viewer. SVG stands for Scalable Vector Graphics.

We’ve talked about the HTML canvas element as another means to come to this end, but the SVG methods are more straightforward in their creation.

For today’s tutorial we follow the advice at this wonderful tutorial and wrap it in PHP, so that you can specify your own parameters. Hope you find it very useful, and easy.

This demonstrates to you that if you have some great static HTML you can keep that great static content and present a dynamic version the user can play around with, and learn from, by adding that PHP server-side content. For today’s PHP interface we got the HTML to use an HTML form of the relevant shape’s characteristics and post this data back to the same PHP webpage, analyzing the $_POST[] data to fill in the static HTML parameter values with user-defined parameter alternatives.

Today we have PHP and Javascript programmable source code you could call SVG_Primer.php and here is its live run.
